Automatic programable circular knife sharpener or manufacturing of circular knives with full enclosure

Rekord CK 500NC

Automatic Single Head Grinder for Slitters up to 20″ (22″ with slight modification)

Single Grinding head easily adjusts from -10° to +70° bevel angles. Automatically grind a wide variety of circular knives, including top and bottom slitters, and single and multiple bevels. Automatic knife rotation driven by geared motor at 20 RPM. Automatic infeed programmable per pass and total infeed.

Media

Details

Request Info & Pricing

Product Details

Description Features & Benefits Specifications Accessories

Description

Common for shops looking to sharpen Larger Circular Knives and a variety of Single+Double bevel, Traditional or Counter bevel Knives

NC Control allows programing rough, finish + spark out cycle with memory
Ability to match diameters on multiple blades (bottom or counter knives) and match bevel on double bevel blades
Ability to grind single bevel knives from -10 to +70 degree bevel angles
Automatic knife rotation driven by geared motor at 14 RPM
Manual Central Lubrication System
Roller bearing guide construction of slides for increased accuracy and durability
Grinds with CBN, Diamond, or conventional abrasive wheels

Features & Benefits

Specifications

Accessories

Rekord CK 500NC Optional Accessories

Electronic Speed Variator for Knife Rotation (Knife rotation speed adjustable from 7 to 30 RPM)(9 to 40, 19 to 64, 30 to 100RPM also available factory only by gear box reduction)
Full Cabin Enclosure with low voltage machine lamp
Automatic central lubrication system

Coolant and Mist Extraction Systems
Standard Coolant System Specs To 35 micron, 4 GPM, 14 Gallon Tank

Automatic Paper roll filtration system To 35 micron, 13 GPM, 45 Gallon Tank
Magnetic Separator for HSS – Can be used with standard system or auto paper roll system
Mist extraction system for use with Synthetic coolants. Required for full cabin machines, but may be supplied by customer

Tool Holding
Because Circular knives vary significantly as to diameter, bore, bevel angle, and general configuration, Knife holding flanges are quoted at request. Generally Clamping Flanges run from $200 to $800.
Customers who are currently grinding circular knives on another machine, commonly find that they can use the clamping devices they already own. The CK500 comes standard with a 16mm shaft for holding the knives.
